2ch compatible all-in-one streaming encoder

Model number: MS-SC6D0N1AIO

SKU 4562393846994 Category

This is an encoder that can encode 3-channel video sources in real time, including 1-channel SDI input and 1-channel from various input sources including HDMI, and composite screen (PGM) for live distribution. Since it supports the latest distribution methods such as SRT and RTSP, as well as RTMP format distribution, it is also ideal for live distribution services such as Youtube and Facebook Live.

Official support for MUSIC/SLASH

SC6D0N1 AIO is MUSIC/SLASH official compatible encoder.


One unit supports various input sources

This single unit can handle various input sources such as 3G/HD/SD-SDI, HDMI, DVI, analog RGB, component, composite, and S-video. Audio can be selected from 2ch embedded audio or stereo analog line input.
* Operation may become unstable if the input signal is interrupted during operation or if the resolution or frame rate of the input signal changes.
In particular, if a signal other than the supported input resolution is input, the encoder must be restarted. Depending on the device on the video output side, such as a personal computer, the output signal may be unstable and an incompatible signal may be input. Turn on the power of the encoder after the signal is stably input to the encoder, or use a frame synchronizer that can stably input the resolution and frame rate before inputting the signal to the encoder. Please design so that the signal to be connected and input to the encoder is kept constant.

Switching and layout display in PGM mode

It can be used like a simple switcher that switches between SDI and one other input video source, picture-in-picture that freely arranges and displays two video sources, and loop that automatically switches video at a set time. PGM channels that support 3 modes can be streamed or recorded as they are.

2 types for each channel Total 6 encoders built-in

Each channel has two encoders, and you can set encoding parameters and distribution destinations for each encoder. It is also possible to mix HEVC and H.264 formats in one channel. A total of 6 encoders are built into this unit, including 2 channels and PGM.

PC not required Operation possible with this unit alone

By connecting a computer monitor, mouse, and keyboard, it is possible to perform all settings and operations of this unit without a computer.

Also supports receiving and displaying IP streams

By using it in combination with another SC6D0 series, you can display, record, and redistribute the sent stream.

OSD display

A 4-plane OSD layer is provided for each input channel, and text, date and time, and still images can be set individually.
*OSD is not displayed when using stream as video source on CH1/CH2. OSD can be displayed for PGM even when the stream is used as the video source.

Support recording

Video can be recorded by connecting a recording medium to the front USB3.0 connector. There is also a function that automatically uploads the recorded video to the set FTP server and automatically deletes the file that has been transferred, so it is possible to record for a long time by combining with the FTP server.
*Because it is necessary to write the necessary data at the end of recording, recording will automatically end when the remaining capacity of the recording medium reaches 2GB. When using the recording function, secure enough free space for the expected recording time.

Still image display function

You can set a still image as the video input source. It is also possible to automatically display a still image when the input signal is interrupted.

Supported JPEG formats

Resolution: 1920 x 1080 or less DPI
: 72DPI
Color depth: 8 bits/channel
When using PGM, you can use it even if no video signal is input to CH1/CH2.

Simultaneous operation of streaming and recording

Up to 6 types of streaming, 2 types for each channel, can be operated simultaneously for each encoder setting of each channel.

Supports NDI HX (optional feature)

SC6D0N1 AIO has a trial version function that can operate as an NDI HX (H.264 format) encoder and decoder for only 30 minutes. By purchasing an optional license, you will be able to use it without the 30-minute limit.
*The NDI HX function is tested for connection compatibility using NDI Video Monitor. Please be sure to perform a preliminary connection test using the evaluation machine and trial version before purchasing.

Control via the cloud (optional feature)

The SC6D0N1 AIO has the ability to change and control settings via the Internet. Please contact us for more information.

please note

The functions that can be operated simultaneously differ depending on the settings of each function. Each function can be set up to the upper limit, but not all functions can be used with the upper limit set. When using various functions, please set so that the usage rate of the CPU of this machine is within about 80% on average. If you set a high CPU load factor and use it, distribution and recording may not work properly.

Supported frame rate Supports up to 1920×1080 50/60 fps
Supported encoding resolution Built-in downscaling function to a minimum of 160 x 120
Number of encodings supported Input 1 x 2 types, Input 2 x 2 types, PGM x 2 types
encoding mode Real-time hardware encoding
network interface RJ45: 10/100/1000Mbps Ethernet (built-in DHCP client function)
Video input terminal ■ Input 1
BNC x 3 (shared with component/composite/S-video)
DVI-I x 1 (DVI/Analog RGB)
HDMI x 1
■ Input 2
BNC x 1 3G/HD/SD-SDI (3G-SDI Level b non correspondence)
audio input terminal ■ Supports input 1
RCA x 2 (stereo analog audio input)
Stereo mini jack x 1 (stereo analog audio input)
■ Embedded audio (SDI / HDMI / DVI-D)
Supported input resolution 1920×1080 (60p/50p/30p/25p/24p/60i/50i)
1280×720 (60p/50p) / 1280×1024 (60p)
1280×960 (60p) / 1024×768 (60p) / 800×600 (60p) / 720×480 (60p/60i) / 640×480 (60p) / 720×576 (50p/50i)
*Please also check here
Video output terminal HDMI x 1
encoding mode ■Video
H.264 / H.265, Main / High Profile, Maximum bit rate 64Mbps
Encoding supports progressive only. Interlaced video signals are encoded progressively. (Example: 60i → 30p)Audio
AAC-LC, maximum bit rate 384kbps, sampling rate 48KHz, 16bit
Supported delivery protocols HLS(Pull) , RTMP/RTMPS(Publish)
RTSP over HTTP/UDP(RTSP elementary stream)
TS over UDP (Unicast) , TS over RTSP
SRT(Caller, Listener)
Number of supported delivery streams Input 1 , Input 2 , PGM 2 each
Number of supported recording streams Input 1 , Input 2 , PGM 2 each
Number of supported decoding streams 2 lines (exclusive with signal input) / Video is displayed as PGM output You
can receive and display files or streams recorded by this product
HDMI output mode PGM screen output, 1920×1080 50/60P
OSD Input 1, input 2, 4 planes for each PGM, date and time, still image can be displayed
external control RS-485
control button Distribution/recording/input source switching (excluding SDI)
USB terminal USB 3.0 compatible x 1 (supports recording storage, keyboard, mouse connection)
recording mode Supports MP4/TS/MOV format
PGM mode Full screen display (displays input 1 or input 2)
picture-in-picture (display position and size adjustable)
switching display (switching interval 1-60 seconds, set in 1-second increments)
PGM mixer Supports mixing output to CH1 Embedded Audio, CH2 Embedded Audio, Line in/Mic PGM channels
others Device name, channel name setting
Disk format
Importing and exporting settings
Firmware update
Time adjustment by NTP
power supply DC input 12V2A (supplied from AC adapter)
power consumption About 9.6W
External size 150(W) x 82(D)x 40(H) mm *Not including protrusions
mass Approximately 0.6 kg (excluding AC adapter)

About specifications

The listed specifications describe everything that can be set, but not all functions can be used unlimitedly. It may be restricted by the standard or by the CPU load factor of the function used. If the CPU load factor exceeds 80%, the operation may be affected, so it is necessary to use it at a load factor of 80% or less.

Encoding in H.265 (HEVC)

If you set to deliver with RTMP, the RTMP standard does not support H.265, so even if the encoding mode is H.265, it is forcibly encoded with H.264 and delivered. . Other streams and recordings using the same encoder are also affected by this behavior.

When set to RTSP or HLS distribution, this unit will encode in H265, but if the playback environment does not support H.265 decoding, the video will not be displayed.
